PRO MP2422C

PANEL SIZE
PANEL RESOLUTION
REFRESH RATE
RESPONSE TIME
PANEL TYPE
BRIGHTNESS (NITS)
VIEWING ANGLE
ASPECT RATIO
CURVATURE
CONTRAST RATIO
sRGB
ACTIVE DISPLAY AREA (MM)
PIXEL PITCH (H X V)
SURFACE TREATMENT
DISPLAY COLORS
COLOR BIT
VIDEO PORTS
AUDIO PORTS
KENSINGTON LOCK
SPEAKER
VESA MOUNTING
POWER TYPE
POWER INPUT
ADJUSTMENT (TILT)
DIMENSION (W X H X D)
CARTON DIMENSION (W X H X D)
WEIGHT (NW / GW)
CERTIFICATES
VIDEO INPUT COMPATIBILITY
Note

PANEL SIZE

23.6"

PANEL RESOLUTION

1920 x 1080 (FHD)

REFRESH RATE

100Hz

RESPONSE TIME

4ms (GTG Min.) / 1ms MPRT

PANEL TYPE

BRIGHTNESS (NITS)

250 cd/m2

VIEWING ANGLE

178°(H) / 178°(V)

ASPECT RATIO

16:9

CURVATURE

1500R

CONTRAST RATIO

3000:1

sRGB

98% (CIE 1976)

ACTIVE DISPLAY AREA (MM)

521(H) x 293(V)

PIXEL PITCH (H X V)

0.272(H) x 0.272(V)

SURFACE TREATMENT

Anti-glare

DISPLAY COLORS

16.7M

COLOR BIT

8 bits

VIDEO PORTS

1x HDMI (1.4b)
1x D-Sub (VGA)

AUDIO PORTS

1x Line-in
1x Headphone-out

KENSINGTON LOCK

Yes

SPEAKER

2x 2W

VESA MOUNTING

100 x 100 mm

POWER TYPE

Internal Power

POWER INPUT

100~240V, 50~60Hz

ADJUSTMENT (TILT)

-7° ~ 22°

DIMENSION (W X H X D)

539.8 x 414.1 x 203.0 mm
(21.25 x 16.30 x 7.99 inch)

CARTON DIMENSION (W X H X D)

600 x 400 x 140 mm
(23.62 x 15.75 x 5.51 inch)

WEIGHT (NW / GW)

2.95kg / 4.39kg

CERTIFICATES

CB/CE
Energy Star

VIDEO INPUT COMPATIBILITY

PC, Mac, PS5™, PS4™, Xbox, Mobile, Notebook
* All trademarks and the registered trademarks are the property of their respective owners.

Note

HDMI: 1920 x 1080 (Up to 100Hz)
D-Sub (VGA): 1920 x 1080 (Up to 60Hz)
