| Differences are marked in red | CreatorPro Z16 HX Studio A13VKTA | CreatorPro Z16 HX Studio A13VK | CreatorPro Z16 HX Studio A13VJTA | CreatorPro Z16 HX Studio A13VJ |
| OS |
Windows 11 Home (MSI recommends Windows 11 Pro for business.) Windows 11 Pro |
Windows 11 Home (MSI recommends Windows 11 Pro for business.) Windows 11 Pro |
Windows 11 Home (MSI recommends Windows 11 Pro for business.) Windows 11 Pro |
Windows 11 Home (MSI recommends Windows 11 Pro for business.) Windows 11 Pro |
|---|---|---|---|---|
| CPU | Up to 13th Gen Intel® Core™ i9 HX Processor | Up to 13th Gen Intel® Core™ i9 HX Processor | Up to 13th Gen Intel® Core™ i9 HX Processor | Up to 13th Gen Intel® Core™ i9 HX Processor |
| Display |
16” QHD+ (2560x1600), 165Hz, IPS-Level Support MSI Pen (Optional) Touchscreen |
16” QHD+ (2560x1600), 165Hz, MiniLED, IPS-Level Support MSI Pen (Optional) |
16” QHD+ (2560x1600), 165Hz, IPS-Level Support MSI Pen (Optional) Touchscreen |
16” QHD+ (2560x1600), 165Hz, MiniLED, IPS-Level Support MSI Pen (Optional) |
| Chipset | Intel® HM770 | Intel® HM770 | Intel® HM770 | Intel® HM770 |
| Graphics | NVIDIA RTX™ 3000 Ada Generation Laptop GPU (8GB GDDR6) powers advanced AI with 319 AI TOPS Up to 2160MHz Boost Clock 90W Maximum Graphics Power with Dynamic Boost. *May vary by scenario | NVIDIA RTX™ 3000 Ada Generation Laptop GPU (8GB GDDR6) powers advanced AI with 319 AI TOPS Up to 2160MHz Boost Clock 90W Maximum Graphics Power with Dynamic Boost. *May vary by scenario | NVIDIA RTX™ 2000 Ada Generation Laptop GPU (8GB GDDR6) powers advanced AI with 232 AI TOPS Up to 2340MHz Boost Clock 90W Maximum Graphics Power with Dynamic Boost. *May vary by scenario | NVIDIA RTX™ 2000 Ada Generation Laptop GPU (8GB GDDR6) powers advanced AI with 232 AI TOPS Up to 2340MHz Boost Clock 90W Maximum Graphics Power with Dynamic Boost. *May vary by scenario |
| Storage Capability | 1x M.2 SSD slot (NVMe PCIe Gen5) Compatible | 1x M.2 SSD slot (NVMe PCIe Gen5) Compatible | 1x M.2 SSD slot (NVMe PCIe Gen5) Compatible | 1x M.2 SSD slot (NVMe PCIe Gen5) Compatible |
| Webcam | IR FHD type (30fps@1080p) | IR FHD type (30fps@1080p) | IR FHD type (30fps@1080p) | IR FHD type (30fps@1080p) |
| Keyboard | Single Backlit Keyboard (White) | Single Backlit Keyboard (White) | Single Backlit Keyboard (White) | Single Backlit Keyboard (White) |
| Communication | Intel® Killer™ AX Wi-Fi 6E + Bluetooth 5.3 | Intel® Killer™ AX Wi-Fi 6E + Bluetooth 5.3 | Intel® Killer™ AX Wi-Fi 6E + Bluetooth 5.3 | Intel® Killer™ AX Wi-Fi 6E + Bluetooth 5.3 |
| Security |
Fingerprint Security Discrete Trusted Platform Module(dTPM) 2.0 Firmware Trusted Platform Module(fTPM) 2.0 |
Fingerprint Security Discrete Trusted Platform Module(dTPM) 2.0 Firmware Trusted Platform Module(fTPM) 2.0 |
Fingerprint Security Discrete Trusted Platform Module(dTPM) 2.0 Firmware Trusted Platform Module(fTPM) 2.0 |
Fingerprint Security Discrete Trusted Platform Module(dTPM) 2.0 Firmware Trusted Platform Module(fTPM) 2.0 |
| Audio | 4x 2W Speaker | 4x 2W Speaker | 4x 2W Speaker | 4x 2W Speaker |
| Audio Jack | 1x Mic-in/Headphone-out Combo Jack | 1x Mic-in/Headphone-out Combo Jack | 1x Mic-in/Headphone-out Combo Jack | 1x Mic-in/Headphone-out Combo Jack |
| I/O Ports | 1x Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.0) 1x Type-C (USB3.2 Gen2 / DisplayPort™) 1x Type-A USB3.2 Gen2 1x SD Express Card Reader | 1x Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.0) 1x Type-C (USB3.2 Gen2 / DisplayPort™) 1x Type-A USB3.2 Gen2 1x SD Express Card Reader | 1x Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.0) 1x Type-C (USB3.2 Gen2 / DisplayPort™) 1x Type-A USB3.2 Gen2 1x SD Express Card Reader | 1x Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.0) 1x Type-C (USB3.2 Gen2 / DisplayPort™) 1x Type-A USB3.2 Gen2 1x SD Express Card Reader |
| Memory | Up to DDR5-5600 Max 64GB 2 Slots | Up to DDR5-5600 Max 64GB 2 Slots | Up to DDR5-5600 Max 64GB 2 Slots | Up to DDR5-5600 Max 64GB 2 Slots |
| Sensor | 1x Ambient Light Sensor | 1x Ambient Light Sensor | 1x Ambient Light Sensor | 1x Ambient Light Sensor |
| Battery | 4-Cell 90 Battery (Whr) | 4-Cell 90 Battery (Whr) | 4-Cell 90 Battery (Whr) | 4-Cell 90 Battery (Whr) |
| AC Adapter | 280W adapter (for i9) / 240W adapter (for i7) | 280W adapter (for i9) / 240W adapter (for i7) | 280W adapter (for i9) / 240W adapter (for i7) | 280W adapter (for i9) / 240W adapter (for i7) |
| Dimension (WxDxH) | 359 x 256 x 19 mm | 359 x 256 x 19 mm | 359 x 256 x 19 mm | 359 x 256 x 19 mm |
| Weight (w/ Battery) | 2.39 kg | 2.39 kg | 2.39 kg | 2.39 kg |
| Color | Lunar Gray | Lunar Gray | Lunar Gray | Lunar Gray |
