Specification N250GTS Twin Frozr 1G OC

N250GTS Twin Frozr 1G OC

Graphics Processing Unit
Interface
Core Clocks
Memory Speed
Memory Size
Memory Type
Memory Bus
HDCP Support
DirectX Version Support
OpenGL Version Support
Memory Bandwidth (GB/sec)
DVI Connectors
D-SUB Connectors
HDMI Connectors
RAMDAC speed (MHz)

Graphics Processing Unit

GeForce GTS 250

Interface

PCI Express x16 2.0

Core Clocks

738/760

Memory Speed

2000/2300

Memory Size

1024

Memory Type

GDDR3

Memory Bus

256bit

HDCP Support

DirectX Version Support

10.0

OpenGL Version Support

2.1

Memory Bandwidth (GB/sec)

70.4

DVI Connectors

D-SUB Connectors

2(optional, via DVI to D-Sub adaptor)

HDMI Connectors

1(optional, via DVI to HDMI™ adaptor)

RAMDAC speed (MHz)

400

MSI exclusive Twin Frozr thermal design

Dual PWM Fan
Provides up to 50% better thermal efficiency and direct air flow to cool down power module(MOSFET, Capacitors), memory and GPU.
Multiple Heatpipes
Transfer heat to the fins under the dual PWM fans, and the fans dissipate heat directly.
Triple-layer design
Fine, heatpipes, and copper base are all connected together; creates the shortest path to dissipate the heat of GPU, and to improve the cooling performance.
Extra Large Copper-inckel Base
Dissipates heat from GPU to each fin, faster than traditional aluminum base.
Extra Large Heatsink
Provides up to 30% larger area for heat dissipation.

MSI exclusive Military Class

Hi-c CAP (Highly-Conductive Capacitor)
The core of Hi-c CAP is "Trantalum", an extremely rare metal which can be rival to Platinum when it comes to stability. MSI use Hi-c CAP on GPU power supply module, regulate GPU voltage to achieve highest stability and overclocking.
SSC (Solid State Choke)
SSC is a new generation form-in-all choke. Unlike the traditional chokes, Solid State Choke, which has no sequarate part inside, generate no high frequency buzz noise. Its higher maximum current output is also specifically designed for overclocking.
All Solid Capacitor
achieves 10 years lifetimes, lower temperature and offer better power efficiency.

Video Output Function

Dual-link DVI-I x 2
VGA (via DVI to D-Sub adaptor) x 2
HDMI™ (DVI to HDMI™ adaptor) x 1

Bundle MSI developed driver and utilities

MSI Live Update Series(Live Graphics Card BIOS & Live Graphics Card Driver)
Automatically online download & update Graphics Card BIOS & Drivers, reduce the risk of getting the wrong files, and never have the trouble on web site searching.
MSI Graphics Card Driver
MSI Dual Core Center
MSI Live
including all real time life information you need, such as Live MSI Product News, Live Daily Information, Live Personal Schedule Manager, Live Search and more.
Adobe Acrobat Reader
Microsoft® DirectX
Norton Internet Security™ 2008 60 days Trial
-Blocks online identity theft by phishing Web sites
-Detects and eliminates spyware
-Removes viruses and Internet worms automatically
-Protects against hackers

Product Accessories


	Optional	Optional

MSI Reminds You...
• The accessories will probably be different according to the different selling areas of product models. For details of accessories, please refer to the descriptions on the product package.
