| Differences are marked in red | Katana GF66 11UG | Katana GF66 11UE | Katana GF66 11UD | Katana GF66 11UC |
| OS |
Windows 10 Home (MSI recommends Windows 11 Pro for business.) FREE Upgrade to Windows 11* |
Windows 10 Home (MSI recommends Windows 11 Pro for business.) FREE Upgrade to Windows 11* |
Windows 10 Home (MSI recommends Windows 11 Pro for business.) FREE Upgrade to Windows 11* |
Windows 10 Home (MSI recommends Windows 11 Pro for business.) FREE Upgrade to Windows 11* |
|---|---|---|---|---|
| CPU | Up to 11th Gen. Intel® Core™ i7 Processor | Up to 11th Gen. Intel® Core™ i7 Processor | Up to 11th Gen. Intel® Core™ i7 Processor | Up to 11th Gen. Intel® Core™ i7 Processor |
| Display | 15.6" FHD (1920x1080), 144Hz, IPS-Level | 15.6" FHD (1920x1080), 144Hz, IPS-Level |
15.6" FHD (1920x1080), IPS-Level 15.6" FHD (1920x1080), 144Hz, IPS-Level |
15.6" FHD (1920x1080), IPS-Level 15.6" FHD (1920x1080), 144Hz, IPS-Level |
| Chipset | Intel® HM570 | Intel® HM570 | Intel® HM570 | Intel® HM570 |
| Graphics |
NVIDIA® GeForce RTX™ 3070 Laptop GPU 8GB GDDR6 Up to 1315MHz Boost Clock 85W Maximum Graphics Power with Dynamic Boost. *May vary by scenario |
NVIDIA® GeForce RTX™ 3060 Laptop GPU 6GB GDDR6 Up to 1435MHz Boost Clock 85W Maximum Graphics Power with Dynamic Boost. *May vary by scenario |
NVIDIA® GeForce RTX™ 3050Ti Laptop GPU, 4GB GDDR6 Up to 1435MHz Boost Clock 60W Maximum Graphics Power. *May vary by scenario |
NVIDIA® GeForce RTX™ 3050 Laptop GPU 4GB GDDR6 128-bit Up to 1450MHz Boost Clock 60W Maximum Graphics Power. *May vary by scenario |
| Memory | DDR4-3200 Max 64GB 2 Slots | DDR4-3200 Max 64GB 2 Slots | DDR4-3200 Max 64GB 2 Slots | DDR4-3200 Max 64GB 2 Slots |
| Storage Capability | 2x M.2 SSD slot (NVMe PCIe Gen3) | 2x M.2 SSD slot (NVMe PCIe Gen3) | 1x M.2 SSD slot (NVMe PCIe Gen3) | 1x M.2 SSD slot (NVMe PCIe Gen3) |
| Webcam | HD type (30fps@720p) | HD type (30fps@720p) | HD type (30fps@720p) | HD type (30fps@720p) |
| Keyboard | Single Backlit Keyboard (Red) | Single Backlit Keyboard (Red) | Single Backlit Keyboard (Red) | Single Backlit Keyboard (Red) |
| Communication | Gb LAN 802.11 ax Wi-Fi 6 + Bluetooth v5.2 | Gb LAN 802.11 ax Wi-Fi 6 + Bluetooth v5.2 | Gb LAN 802.11 ax Wi-Fi 6 + Bluetooth v5.2 | Gb LAN 802.11 ax Wi-Fi 6 + Bluetooth v5.2 |
| Audio | 2x 2W Speaker | 2x 2W Speaker | 2x 2W Speaker | 2x 2W Speaker |
| Audio Jack | 1x Mic-in/Headphone-out Combo Jack | 1x Mic-in/Headphone-out Combo Jack | 1x Mic-in/Headphone-out Combo Jack | 1x Mic-in/Headphone-out Combo Jack |
| I/O Ports | 1x Type-C USB3.2 Gen1 2x Type-A USB3.2 Gen1 1x Type-A USB2.0 1x HDMI™ 2.1 (4K @ 60Hz) 1x RJ45 | 1x Type-C USB3.2 Gen1 2x Type-A USB3.2 Gen1 1x Type-A USB2.0 1x HDMI™ 2.1 (4K @ 60Hz) 1x RJ45 | 1x Type-C USB3.2 Gen1 2x Type-A USB3.2 Gen1 1x Type-A USB2.0 1x HDMI™ 2.1 (4K @ 60Hz) 1x RJ45 | 1x Type-C USB3.2 Gen1 2x Type-A USB3.2 Gen1 1x Type-A USB2.0 1x HDMI™ 2.1 (4K @ 60Hz) 1x RJ45 |
| Battery | 3-Cell 53.5Whr / 4-Cell 90Whr Battery (Whr) | 3-Cell 53.5 Battery (Whr) | 3-Cell 53.5 Battery (Whr) | 3-Cell 53.5 Battery (Whr) |
| AC Adapter | 180W adapter | 180W adapter | 150W adapter | 150W adapter |
| Dimension (WxDxH) | 359 x 259 x 24.9 mm | 359 x 259 x 24.9 mm | 359 x 259 x 24.9 mm | 359 x 259 x 24.9 mm |
| Weight (w/ Battery) | 2.25 kg | 2.25 kg | 2.25 kg | 2.25 kg |
| Color | Black | Black | Black | Black |
| Xbox Game Pass | – | One month of PC Game Pass *Spec and bundle offer may vary by model and by country. Please refer to the final specification of the product purchased for Xbox Game Pass pre-installed details. | – | – |
