MAG-27CQ6F

MAG 27CQ6F

Panel Size
Active Display Area (mm)
Curvature
Panel Type
Panel Resolution
Pixel Pitch (H x V)
Aspect Ratio
Brightness (nits)
Contrast Ratio
DCR
Signal Frequency
ACTIVATED RANGE
Refresh Rate
Response time
DYNAMIC REFRESH RATE TECHNOLOGY
HDR Support
Video ports
Audio ports
Viewing Angle
Adobe RGB / DCI-P3 / sRGB
Surface Treatment
Display Colors
Frameless Design
Power Type
Power Input
Adjustment (Tilt)
Kensington Lock
VESA Mounting
Weight (NW / GW)
Dimension (W x D x H)
Carton Dimension (W X D X H)
Note

Panel Size

27" (69 cm)

Active Display Area (mm)

596.736(H) x 335.664(V)

Curvature

Curve 1500R

Panel Type

Rapid VA

Panel Resolution

2560 x 1440 (WQHD)

Pixel Pitch (H x V)

0.2331(H) x 0.2331(V)

Aspect Ratio

16:9

Brightness (nits)

300 (Typ.)

Contrast Ratio

5000:1 (Typ.)

100000000:1

Signal Frequency

70.56KHz-266.4KHz / 48Hz-180Hz

ACTIVATED RANGE

48~180Hz

Refresh Rate

180Hz

Response time

0.5ms (GtG, Min.)

DYNAMIC REFRESH RATE TECHNOLOGY

AMD FreeSync™

HDR Support

HDR Ready

Video ports

1 x DisplayPort (1.4)
2 x HDMI™ (2.0b)

Audio ports

1 x Headphone Out

Viewing Angle

178° (H) / 178° (V)

Adobe RGB / DCI-P3 / sRGB

80% / 80% / 105%

Surface Treatment

Anti-glare

Display Colors

1.07B , 10 bits (8 bits + FRC)

Frameless Design

Yes

Power Type

Power Cable

Power Input

100 ~ 240V, 50/60Hz

Adjustment (Tilt)

-5° ~ 20°

Kensington Lock

Yes

VESA Mounting

100 x 100 mm

Weight (NW / GW)

3.95kg / 5.65kg

Dimension (W x D x H)

610 x 250 x 451.6 mm
610 x 90.4 x 362.5 mm(without stand)

Carton Dimension (W X D X H)

WW carton: 684 x 158 x 475 mm
Outer: 704 x 178 x 508 mm

Note

Display Port: 2560x1440 (Up to 180Hz)
HDMI™ 2.0: 2560x1440 (Up to 144Hz)

*Adobe RGB, DCI-P3 and sRGB follow CIE1976 Standard
