Chipset | INTEL H610 |
---|---|
CPU | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® ProcessorsLGA 1700 |
Memory |
4x DDR4Memory Support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDECSupports Dual-Channel mode Supports non-ECC, un-buffered memory |
Onboard Graphics | 1x HDMI™Support HDMI™ 1.4, maximum resolution of 4K 30Hz*1x DisplayPortSupport DP 1.4, maximum resolution of 4K 60Hz*1x cmsfront_lang_auto_spec.sku_column_title_mb_173Support DVI-D, maximum resolution of 1920x1200 60Hz1x VGASupport VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
Slot | 2x PCI-E x16 slot1x PCI-E x1 slot1x PCI slot (Qty)PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) |
Audio | Realtek® ALC897 Codec7.1-Channel High Definition Audio |
Storage | 1x M.2M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_1 slot. |
USB | 4x USB 2.0 (Rear)4x USB 2.0 (Front)1x USB 5Gbps Type A (Rear)1x USB 5Gbps Type C (Rear)2x USB 5Gbps Type A (Front) |
LAN | Intel® I219V 1Gbps LAN |
Internal IO | 1x Power Connector(ATX_PWR)1x Power Connector(CPU_PWR)1x CPU Fan1x System Fan2x Front Panel (JFP)1x Chassis Intrusion (JCI)1x Front Audio (JAUD)1x Printer Port (JLPT)1x Com Port (JCOM)1x TPM pin header(Support TPM 2.0)4x USB 2.0 ports2x USB 5Gbps Type A ports |
WIRELESS LAN & BLUETOOTH | 1x M.2 slot with E-key for PCIe WiFi module only |
LED FEATURE | 4x EZ Debug LED |
BACK PANEL PORTS |
|
OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
BOX CONTENT | |
PCB Info | mATX243.84mmx243.84mm |
